Sachs engine & gearbox

GPO stud bolt "Divertimento" & "Diablo" cylinder | Sachs 502, 50/2, 50/3, 50/4

Manufacturer: GPO · Material: Steel · Surface: blackened · Diameter: 5.3 mm · Thread type: M6x1 (standard thread) · Nominal diameter (thread): 6 mm · Total length: 62 mm · Thread length: 7.8 mm · Thread length: 11.8 mm · Strength class: 10.9

AKOA 43 mm cylinder kit "Power-Edition" with head (selection) | Sachs 503 2AL, AAL, 2BL, ABL

Nominal diameter: 43 mm · Manufacturer: AKOA · Material: Aluminum · Surface: Nickel silicon carbide (colloquially known as Nikasil) · Displacement: 63 ccm · Crankshaft stroke: 43 mm · Ø cylinder neck: 45.5 mm · Ø Outlet outside: 25.9 mm · Ø outlet inside: 20.5 mm · Ø Inlet inside: 15.8 mm · Thread inlet: M6x1 (standard thread) · Hole spacing inlet: 32 mm · Ø piston pin (B): 12 mm · Outlet type: clamped · Number of fixing points: 4 pcs · Hole pattern [mm]: 40 x 60 / 37 x 37 · Camouflaged: No · Area of application: Tuning

Ignition cover (version with speedometer drive) | Sachs 50

Material: Aluminum · Pony OEM number: A1001 · Sachs OEM no.: 0211 066 001

GPO pad spring clutch | Sachs 502 1A / 1B

Manufacturer: GPO · Material: Spring steel · Total length: 250 mm · Material thickness: 0.3 mm

GPO clutch spring | Sachs 502 1A / 1B

Spring design: Tension spring · Manufacturer: GPO · Material: Spring steel · Ø wire: 0.9 mm · Ø outside: 4.1 mm · Total length: 208 mm

Sprocket | Sachs 503 AC / ADV

Material: Steel · Ø inside: 18 mm · Number of teeth: 31 pcs · Pony OEM number: A4490

swiing® ingenious 41 mm gasket cylinder head | Sachs 503, 502, 50/2, 50/3, 50/4

Thickness: 0.4 mm · Manufacturer: swiing® ingenious parts · Material: Aluminum · Ø cylinder: 41 mm · Ø inside: 41.3 mm · Reinforced: No · Nominal diameter: 41 mm · Place of use: Cylinder head · Hole pattern [mm]: 37 x 37

swiing® revival Outer Ring 21/31.5/8.1 Main Shaft, Left | Sachs 50

Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Ø inside: 21 mm · Ø outside: 31.5 mm · Width: 8.1 mm · Sachs OEM no.: 0232 103 000

Oil seal 15/30/5.5 B NBR on clutch side | Sachs 504, 535

Shaft seal type: B - With sheet metal outer casing / one sealing lip. · Manufacturer: Made in Germany · Material: NBR · Ø inside: 15 mm · Ø outside: 30 mm · Place of use: Crankshaft · Width: 5.5 mm · Pony OEM number: A4215 · Sachs OEM no.: 0230 107 000

GPO 38 mm cylinder head with decompressor (pre-assembled) | Sachs 503 2AL / AAL / 2BL / ABL

Manufacturer: GPO · Material: Aluminum · Ø cylinder: 38 mm · Ø outside: 85 mm · Hole pattern [mm]: 37 x 37 · Decompressor: Yes

Oil seal set FPM | Sachs 505

Temperature resistance (min.): 0 - 200 °C · Shaft seal type: AS - With rubberized outer casing / one sealing lip / one dust lip. · Material: FPM - Fluororubber · Ø inside: 15 mm · Ø inside: 16 mm · Ø outside: 24 mm · Ø outside: 30 mm · Ø outside: 32 mm · Ø outside: 35 mm · Width: 4 mm · Width: 5 mm · Width: 5.5 mm · Width: 7 mm

AKOA 43 mm cylinder head for decovalve | Sachs 503 2AL, AAL, 2BL, ABL

Manufacturer: AKOA · Material: Aluminum · Area of application: Tuning · Ø cylinder: 43 mm · Ø outside: 84 mm · Candle thread: short · Height: 29 mm · Number of fixing points: 4 pcs · Hole pattern [mm]: 37 x 37 · Decompressor: M10x1.5

AKOA 38 mm cylinder head for decovalve | Sachs 503 2AL, AAL, 2BL, ABL

Manufacturer: AKOA · Material: Aluminum · Area of application: Tuning · Ø cylinder: 38 mm · Ø outside: 84 mm · Candle thread: short · Height: 29 mm · Number of fixing points: 4 pcs · Hole pattern [mm]: 37 x 37 · Decompressor: M10x1.5 · Alternative version of the Pony OEM number: A1087 · Alternative version of the Sachs OEM number: 0213 142 000

Ignition cover black | Sachs 505, 535 (A5672 & A4452)

Material: Steel · Surface: varnished · Color: black · Ø inside: 125 mm · Ø outside: 128 mm · Height: 31 mm · Pony OEM number: A4452 · Pony OEM number: A5672 · Piaggio OEM number: 0244 167 000

Koyo Sleeve-Type Free-Wheel Clutch Cage (Old Version) | Sachs 503 ABL Automatic

Stock number: RC101410 · Manufacturer: Koyo · Ø inside: 15.88 mm · Ø outside: 22.22 mm · Height: 15.7 mm

AKOA fan cowl right | Sachs 503

Manufacturer: AKOA · Material: Aluminum · Surface: powder-coated · Color: gray · Color: silver · Thread type: M6x1 (standard thread) · Total length: 13065 mm · Width: 65 mm · Height: 140 mm · Number of fixing points: 1 pcs · Pony OEM number: A1061 · Pony OEM number: A5666 · Sachs OEM no.: 0211 142 099

swiing® revival torsion spring clutch lever | Sachs 503 AB / ABL (A5610)

Length spring hook: 10 mm · Leg length: 8 mm · Manufacturer: swiing® revival parts · Material: Spring steel · Surface: galvanized (blue) · Ø inside: 20.5 mm · Ø wire: 2.1 mm · Ø outside: 24.7 mm · Pony OEM number: A5610

swiing® revival torsion spring clutch lever | Sachs 504, 505, 535, 508 (A4235)

Length spring hook: 13.5 mm · Leg length: 6.5 mm · Manufacturer: swiing® revival parts · Material: Spring steel · Ø inside: 8.1 mm · Ø wire: 1.7 mm · Ø outside: 11.5 mm · Total length: 34.5 mm · Pony OEM number: A4235 · Hercules OEM number: S00 0239 136 200 · Sachs OEM no.: 0239 136 200

Tivedens engine 41 mm cylinder kit S3 | Sachs 50/2 (DE), 50/3, 50/4

Manufacturer: Tivedens Motor AB · Material: Gray cast iron · Surface: varnished · Area of application: Tuning · Displacement: 55 ccm · Crankshaft stroke: 42 mm · Nominal diameter: 41 mm · Ø cylinder neck: 44 mm · Ø Outlet outside: 40 mm · Ø outlet inside: 29.5 mm · Inlet window: 17 x 15 mm · Thread inlet: M5x0.8 (standard thread) · Hole spacing inlet: 31 mm · Ø piston pin (B): 12 mm · Outlet type: Union nut · Number of fixing points: 4 pcs · Thread outlet: MF40x1.5 (fine pitch thread)

Tivedens engine 41 mm cylinder kit S4 | Sachs 50/2 (DE), 50/3, 50/4

Manufacturer: Barikite · Manufacturer: Tivedens Motor AB · Material: Gray cast iron · Area of application: Tuning · Displacement: 55 ccm · Crankshaft stroke: 42 mm · Nominal diameter: 41 mm · Ø cylinder neck: 45 mm · Ø Outlet outside: 40 mm · Ø outlet inside: 18 mm · Ø outlet inside: 30 mm · Inlet window: 17 x 15 mm · Thread inlet: M5x0.8 (standard thread) · Hole spacing inlet: 31 mm · Ø piston pin (B): 12 mm · Outlet type: Union nut · Number of fixing points: 4 pcs · Thread outlet: MF36x1.5 (fine pitch thread)

swiing® ingenious Cylinder Head Gasket 41 mm Copper | Sachs 503

Thickness: 0.5 mm · Manufacturer: swiing® ingenious parts · Material: Copper · Ø cylinder: 43 mm · Ø inside: 43.2 mm · Nominal diameter: 43 mm · Place of use: Cylinder head · Hole pattern [mm]: 37 x 37

Cylinder head 38 mm | Sachs 50/2, 50/3

Material: Aluminum · Ø cylinder: 39.5 mm · Ø outside: 103.5 mm · Ø outside: 115 mm · Candle thread: short · Total length: 135.5 mm · Height: 59 mm · Number of fixing points: 4 pcs · Hole pattern [mm]: 6.8 · Decompressor: Yes · Pony OEM number: A1069 / A1070 · Sachs OEM no.: 0213 104 006 / 0213 106 000

GPO 43 mm Cylinder Head with Decompressor (Pre-assembled) | Sachs 503 2AL / AAL / 2BL / ABL

Manufacturer: GPO · Material: Aluminum · Ø cylinder: 43 mm · Ø outside: 85 mm · Hole pattern [mm]: 37 x 37 · Decompressor: Yes

swiing® revival Outer Ring 21/28/6.1 Main Shaft Right | Sachs 502, 50/2, 503

Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Ø inside: 21 mm · Ø outside: 28 mm · Width: 6.1 mm · Pony OEM number: A1146 · Sachs OEM no.: 0232 012 000

swiing® revival Outer Ring 23.5/31.5/6.1 Main Shaft LH | Sachs 502, 50/2, 503, 50/3

Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Ø inside: 23.5 mm · Ø outside: 31.5 mm · Width: 6.1 mm · Pony OEM number: A1157 · Sachs OEM no.: 0232 049 000

swiing® revival outer ring 21/31.5/6.1 main shaft left | Sachs 50, 502, 50/2

Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Ø inside: 21 mm · Ø outside: 31.5 mm · Width: 6.1 mm · Pony OEM number: A1160 · Sachs OEM no.: 0232 103 000

swiing® revival tension spring starter clutch | Sachs 502 1A / 1B

Spring design: Tension spring · Length spring hook: 6 mm · Length spring hook: 7.5 mm · Manufacturer: swiing® revival parts · Material: Spring steel · Ø inside: 3.8 mm · Ø wire: 0.7 mm · Ø outside: 5.2 mm · Total length: 23 mm · Sachs OEM no.: 0259 132 000

GPO 38 mm cylinder head | Sachs 503 2AL / AAL / 2BL / ABL

Manufacturer: GPO · Material: Aluminum · Ø cylinder: 38 mm · Number of fixing points: 4 pcs · Ø outside: 85 mm · Candle thread: short · Hole pattern [mm]: 37 x 37 · Pony OEM number: A1087 · Sachs OEM no.: 0213 142 000

AKOA 40 mm cylinder kit "Power-Edition" with head (selection) | Sachs 503 2AL, AAL, 2BL, ABL

Manufacturer: AKOA · Material: Aluminum · Camouflaged: No · Displacement: 54 ccm · Crankshaft stroke: 43 mm · Nominal diameter: 40 mm · Surface: Nickel silicon carbide (colloquially known as Nikasil) · Ø cylinder neck: 45.5 mm · Ø Outlet outside: 25.9 mm · Ø Inlet inside: 15.8 mm · Number of fixing points: 4 pcs · Thread inlet: M6x1 (standard thread) · Ø outlet inside: 20.5 mm · Area of application: Tuning · Ø piston pin (B): 12 mm · Outlet type: clamped · Hole spacing inlet: 32 mm · Hole pattern [mm]: 40 x 60 / 37 x 37

AKOA 38 mm cylinder kit "Power-Edition" | Sachs 503 2AL, AAL, 2BL, ABL

Nominal diameter: 38 mm · Manufacturer: AKOA · Camouflaged: No · Material: Aluminum · Surface: Nickel silicon carbide (colloquially known as Nikasil) · Displacement: 50 ccm · Crankshaft stroke: 43 mm · Ø cylinder neck: 45.5 mm · Ø Outlet outside: 25.9 mm · Ø outlet inside: 20.5 mm · Ø Inlet inside: 15.8 mm · Hole spacing inlet: 32 mm · Thread inlet: M6x1 (standard thread) · Hole pattern [mm]: 40 x 60 / 37 x 37 · Area of application: Tuning · Number of fixing points: 4 pcs · Ø piston pin (B): 12 mm · Outlet type: clamped · Decompressor: No

13-tooth sprocket | Sachs 502, 503, 504, 505, 535 (A1280)

Chain type: 415H · Ø inside: 15.4 mm · Thickness: 4.4 mm · Material: Steel · Number of teeth: 13 pcs · Recording type: Ø15 x SW12 · Chain pitch: 1/2" x 3/16" · Surface: galvanized (blue) · Total thickness: 6.5 mm · Pony OEM number: A1280 · Sachs OEM no.: 0236 103 000

Oil seal 17/33/7 B NBR crankshaft | Sachs 503 AB / ADV

Place of use: Crankshaft · Temperature resistance (min.): -30 - 100 °C · Shaft seal type: B - With sheet metal outer casing / one sealing lip. · Material: NBR · Width: 7 mm · Ø outside: 33 mm · Ø inside: 17 mm

AKOA 40 mm cylinder kit "Power-Edition" | Sachs 503 2AL, AAL, 2BL, ABL

Nominal diameter: 40 mm · Manufacturer: AKOA · Material: Aluminum · Surface: Nickel silicon carbide (colloquially known as Nikasil) · Displacement: 54 ccm · Crankshaft stroke: 43 mm · Ø cylinder neck: 45.5 mm · Ø Outlet outside: 25.9 mm · Ø outlet inside: 20.5 mm · Ø Inlet inside: 15.8 mm · Thread inlet: M6x1 (standard thread) · Number of fixing points: 4 pcs · Hole spacing inlet: 32 mm · Ø piston pin (B): 12 mm · Outlet type: clamped · Hole pattern [mm]: 40 x 60 / 37 x 37 · Decompressor: No · Camouflaged: No · Area of application: Tuning

AKOA 38 mm cylinder kit "Power-Edition" with head (selection) | Sachs 503 2AL, AAL, 2BL, ABL

Nominal diameter: 38 mm · Manufacturer: AKOA · Material: Aluminum · Surface: Nickel silicon carbide (colloquially known as Nikasil) · Displacement: 50 ccm · Crankshaft stroke: 43 mm · Ø cylinder neck: 45.5 mm · Ø Outlet outside: 25.9 mm · Ø outlet inside: 20.5 mm · Ø Inlet inside: 15.8 mm · Thread inlet: M6x1 (standard thread) · Hole spacing inlet: 32 mm · Ø piston pin (B): 12 mm · Outlet type: clamped · Number of fixing points: 4 pcs · Hole pattern [mm]: 40 x 60 / 37 x 37 · Camouflaged: No · Area of application: Tuning

AKOA 43 mm cylinder kit "Power-Edition" | Sachs 503 2AL, AAL, 2BL, ABL

Nominal diameter: 43 mm · Manufacturer: AKOA · Material: Aluminum · Surface: Nickel silicon carbide (colloquially known as Nikasil) · Displacement: 63 ccm · Crankshaft stroke: 43 mm · Ø cylinder neck: 45.5 mm · Ø Outlet outside: 25.9 mm · Ø outlet inside: 20.5 mm · Ø Inlet inside: 15.8 mm · Thread inlet: M6x1 (standard thread) · Number of fixing points: 4 pcs · Hole spacing inlet: 32 mm · Ø piston pin (B): 12 mm · Outlet type: clamped · Hole pattern [mm]: 40 x 60 / 37 x 37 · Decompressor: No · Camouflaged: No · Area of application: Tuning

swiing® ingenious Cylinder Head Gasket 41 mm Copper | Sachs 503

Place of use: Cylinder head · Thickness: 0.5 mm · Nominal diameter: 41 mm · Manufacturer: swiing® ingenious parts · Material: Copper · Ø cylinder: 41 mm · Ø inside: 41.5 mm · Hole pattern [mm]: 37 x 37

BAD ASS 43 mm cylinder "Diablo" | Sachs 502, 50/2, 50/3, 50/4

Nominal diameter: 43 mm · Manufacturer: BAD ASS · Camouflaged: No · Material: Gray cast iron · Displacement: 61 ccm · Crankshaft stroke: 42 mm · Ø cylinder neck: 46 mm · Ø Outlet outside: 40 mm · Ø outlet inside: 28 mm · Hole spacing inlet: 31 mm · Inlet window: 17 x 15 mm · Thread inlet: M5x0.8 (standard thread) · Hole pattern [mm]: 60 x 40 / 51 x 40 / 37 x 37 · Area of application: Tuning · Number of fixing points: 4 pcs · Ø piston pin (B): 12 mm · Outlet type: Union nut · Thread outlet: MF40x1.5 (fine pitch thread)

GPO 43 mm cylinder head | Sachs 503 2AL / AAL / 2BL / ABL

Ø outside: 85 mm · Manufacturer: GPO · Material: Aluminum · Ø cylinder: 43 mm · Hole pattern [mm]: 37 x 37 · Candle thread: short · Number of fixing points: 4 pcs · Decompressor: No

Meteor piston 38 mm #C | Sachs 503 AB/AC

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 37.98 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 2 mm · Total piston height (E): 51 mm · Number of piston rings (F): 1 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Tolerance group: C · Weight piston kit: 75 g · Pony OEM number: A5685C · Sachs OEM no.: 0286 382 306

Meteor piston 38 mm #D | Sachs 503 AB/AC

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 37.99 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 2 mm · Total piston height (E): 51 mm · Number of piston rings (F): 1 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Tolerance group: D · Weight piston kit: 74 g · Pony OEM number: A5685D · Sachs OEM no.: 0286 382 306

Meteor piston 38 mm #E | Sachs 503 AB/AC

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 38 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 2 mm · Total piston height (E): 51 mm · Number of piston rings (F): 1 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Tolerance group: E · Weight piston kit: 74 g · Pony OEM number: A5685E · Sachs OEM no.: 0286 382 306

Meteor piston 38 mm #A | Sachs 503 AB/AC

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 37.96 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 2 mm · Total piston height (E): 51 mm · Number of piston rings (F): 1 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Tolerance group: A · Pony OEM number: A5685A

Meteor piston ring 40 x 2 (FS)

Manufacturer: Meteor · Nominal diameter: 40 mm · Thick piston ring: 1.65 mm · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Height: 2 mm

NSK E15 shoulder ball bearing 15/35/8 (A1149)

Bearing type: Shoulder bearing · Stock number: E15 · Ø inside: 15 mm · Ø outside: 35 mm · Width: 8 mm · Inner ring width: 8 mm · Manufacturer: NSK · Ball bearing closed: No · Bearing clearance: CN (standard) · Bearing cage: Brass cage ball-guided · Groove ring: No · Material: Brass · Material: Steel · Area of application: Standard · Pony OEM number: A1149 · Sachs OEM no.: 0232 017 006

NSK BO15 shoulder ball bearing 15/40/10 (A4502)

Bearing type: Shoulder bearing · Stock number: BO15 · Ø inside: 15 mm · Ø outside: 40 mm · Inner ring width: 10 mm · Manufacturer: NSK · Ball bearing closed: No · Bearing cage: Brass cage ball-guided · Material: Brass · Material: Steel · Area of application: Standard · Width: 10 mm · Pony OEM number: A4502 · Sachs OEM no.: 0932 007 001

Oil seal NBR 15/30/7 B AS | Sachs 503, 50/2

Temperature resistance (min.): -30 - 100 °C · Shaft seal type: B - With sheet metal outer casing / one sealing lip. · Ø inside: 15 mm · Ø outside: 30 mm · Width: 7 mm · Manufacturer: Sachs · Material: NBR · Pony OEM number: A1830 · Sachs OEM no.: 0250 090 000

Gasket cylinder base 0.25 mm | Sachs 50/2, 503 (A1848)

Material: Sealing paper · Place of use: Cylinder base · Thickness: 0.25 mm · Hole pattern [mm]: 60 x 40 · Area of application: Standard · Pony OEM number: A1848 · Sachs OEM no.: 0250 113 100

Shaft seal NBR 12.96/31.5/3.5 Pinion shaft | Sachs 50/2 (A1137)

Place of use: Pinion shaft · Temperature resistance (min.): -30 - 100 °C · Ø inside: 12.96 mm · Ø outside: 31.5 mm · Width: 3.5 mm · Manufacturer: Sachs · Material: NBR · Pony OEM number: A1137 · Sachs OEM no.: 0230 014 100

Fan cowl | Sachs 50/3, 50/4

Material: Aluminum · Color: silver · Number of fixing points: 4 pcs

Plastic Fan Blade, Used | Sachs 503 (A2161)

Manufacturer: Sachs · Material: Plastic · Ø mounting hole: 6 mm · Number of fixing points: 3 pcs · Pony OEM number: A2161 · Sachs OEM no.: 0266 002 000
